Tipe Printer Dot Matrix Printer
Memori 128KB Input Data Buffer
Pins 24 pins
Print Direction
Bi-direction with logic seeking
Control Code ESC/P2 and IBM PPDS emulation
Print Speed
High Speed Draft 10/12 cpi : 347 / 416 cps
Draft 10/12/15 cpi : 260 / 312 / 390 cps
Draft Condensed 17/20 cpi : 222 / 260 cps
LQ 10/12/15 cpi : 86 / 103 / 129 cps
LQ Condensed 17/20 cpi : 147 / 172 cps
Paper Path
Tractor : Rear in, Top out
Manual Insertion : Rear in, Top out
Print Characteristics
Character Sets :
Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15
Bitmap Fonts:
Epson Draft: 10, 12, 15 cpi; Epson Roman & San Serif: 10, 12, 15 cpi, Proportional; Epson Courier: 10, 12, 15 cpi; Epson Prestige: 10, 12 cpi; Epson Script, OCR-B, Orator & Orator-S: 10cpi; Epson Script C: Proporational
Barcode Fonts EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet
Printable Columns
Pitch 10/12/15/17/20 cpi : 80 / 96 / 120 / 137 / 160 cpl
Paper Feeding
Standard : Friction, Push Tractor
Optional : Roll Paper Holder
Copies Original + 3 copies
Line Spacing 4.23mm (1/6") or programmable in increments of 0.118mm (1/216")
Ribbon Cartridge
Standard : Fabric Ribbon Cartridge (Black)
Ribbon Life : Approx. 2.5 million characters (Draft 10cpi, 48 dots/character)
Acoustic Noise Approx. 53dB(A) (ISO 7779 pattern)
Mean Print Volume Between Failure (MVBF) Approx. 20 million lines (Except print head)
Mean Time Between Failure (MTBF) Approx. 10,000 POH (25% Duty)
Print Head Life Approx. 400 million strokes/wire
Control Panel 4 switches and 5 LEDs
Interface
Bi-directional parallel interface (IEEE-1284 nibble mode supported)
USB 2.0 Full-Speed
Serial
Sistem Operasi Microsoft®
Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Windows® 2000 / XP / 7, Microsoft® Windows Vista®Environmental Conditions
Temperature 5 ~ 35°C
Humidty 10 ~ 80% RH
Rated Voltage AC 120V / AC 220 - 240V
Rated Frequency 50Hz - 60Hz
Power Consumption
Operating : Approx. 22W (ISO/IEC 10561 Letter pattern),(ENERGY STAR compliant)
Sleep Mode : Approx. 1.0W (120V) / 1.3W (230V)
Auto Off Mode : Approx. 0.5W
